High Power DIY Aufero Laser Master 10W Laser Power Engraving and Cutting Machine Laser Engraver with New Eye Protection Design

High Power DIY Aufero Laser Master 10W Laser Power Engraving and Cutting Machine Laser Engraver with New Eye Protection Design

Regular price £269.99 GBP
Regular price £251.99 GBP Sale price £269.99 GBP
Sale Sold out
Shipping calculated at checkout.
Color
Ships From

SPECIFICATIONS

Wave Length: 445nm

Safety Precautions: 1.Active Position Protection, 2.Exposure Duration Detection and Limitation, 3.Laser Beam Safety Guard.

Power Rate: S0-S1,000

Origin: Mainland China

Motors: NEMA 17 stepper motors

Motherboard: OLM-MAX-V10 Motherboard

Model Number: Aufero Laser 2

Is Smart Device: NO

Frame Materials: Aluminium+Acrylic

Engraving Speed: 0-15,000MM/Min

Engraving Area: 390x390mm

Control Mode: PMW

Certification: ce

Certification: CE

Brand Name: Aufero

Available Laser Modules: LU2-2/LU2-4 SF/LU2-4 LF/LU2-10A








High Power DIY Aufero Laser Master 10W Engraving and Cutting Machine Laser Engraver with New Eye Protection Design



Specifications:

  • [Aufero AL2]"ORTUR technology, at entry level pricing" AL2 is a budget, entry level machine for the initiated user with stronger system reliability, smooth engraving, faster engraving speed, higher accuracy, and more refined engraving products. Plug&Play Machine!

  • [Overall optimization]Aufero has a longer service life, because the mechanical structure has been optimized and designed to have high precision engraving for a long time. At the same time, Aufero can provide users with more security because it has more security features.

  • [Accessories system update]1. Because it is equipped with the latest OLM-PRO-V1.2 motherboard, the engraving is smoother and more delicate, the engraving accuracy is higher. 2. The circuit system with 24V voltage is upgraded, the current is lower, and the system is safer. 3. Update OLF-V180 seris firmware, which is the most advanced laser engraving machine firmware at present, with more powerful functions.

  • [Product advantage]Ortur Laser 1.8 firmware, qualified for ESP32 MCU, optimizes the motion algorithm, and increases the maximum stepper motors speed to max. 10000mm/mm.

  • [Safety protection]

1.Active Position Protection,
2.Exposure Duration Detection and Limitation,
3.Laser Beam Safety Guard,
4.24V Power Delivery System,
5.Power control system, if shutdown the machine, it would cut the power.


LU2-2 Fixed Focus Laser Module

It has a smaller Luminous Cavity, so it's lower power but high cost-effective, also has a smaller Focal Spot.

Optical Power: 1,000-1,600mW

Voltage: 5-6V

Electric Current: 1.1-1.35A

Wavelength: 445±10NM


TIPS:

1. LU2-2 is good at engraving high-precision pattern, but speed couldn't be set too high.

2. It's not good at cutting.

3. It is not that the smaller the light spot, the better the effect. When engraving photos, you may need to increase the laser spot to get a better picture effect.

4. The competitors may falsely promote the power of similar laser modules as 10W or even 20W, please take care.


LU2-4-LF Optically Compressed Laser Module

With Air Assist Nozzle to ensure very clean cutting edge

Optical Power: 4,500-5,500mW

Voltage: 4.2-5.0V

Electric Current: 3.4-3.6A

Wavelength: 445±10NM


TIPS:

1. LU2-4-LF is good at engraving and better at cutting, and could support a higher speed.

2. It has the air assist, but you need to buy a Air Compressor to support the air assist.

3. It is not that the smaller the light spot, the better the effect. When engraving photos, you may need to increase the laser spot to get a better picture effect.

4. The competitors may falsely promote the power of similar laser modules as 40W or even 60W, please take care.


LU2-4-SF Optically Compressed Laser Module

Better for Engraving

Optical Power: 4,500-5,500mW

Voltage: 4.2-5.0V

Electric Current: 3.6-3.8A

Wavelength: 445±10NM


TIPS:

1. LU2-4-LF is good at cutting and better at engraving harder materials (such as stainless steel and other hard materials), and could support a higher speed..

2. It is not that the smaller the light spot, the better the effect. When engraving photos, you may need to increase the laser spot to get a better picture effect.

3. The competitors may falsely promote the power of similar laser modules as 40W or even 60W, please take care.



LU2-10A Optically Compressed Laser Module

Better for Engraving and Cutting

Optical Power: 10W

Voltage: 4.2-5.0V

Electric Current: 3.6-3.8A

Wavelength: 445±10NM

Specification

General

Brand: Aufero
Model Number: Aufero laser 2
Type: Laser engraving machine
Material: Aluminum + Acrylic
Laser Power: LU2-2 (Electrical Power: 7W, Luminous Power: 1200-1600 mw), LU2-4 SF/LF(Electrical Power:20W, Luminous Power: 5000-5500mw)LU2-10A (Electrical power:40W, Luminous Power 10W)
Laser Reaching Range: 445 ± 5nm
Power By: Power Adapter 24v 3A

Dimensions and Weight

Product weight: 3.000 kg
Package weight: 4.2000 kg
Product size (L x W x H): 582x580x170MM / 22.91"x22.83"x6.69"
Package size (L x W x H): 630x290x120MM / 24.8"x11.42"x4.72"

Package Contents

Package Contents: 1 x Laser Engraving Machine



  • 【Advanced Motherboard】Aufero Laser engraver adopts the advanced motherboard (32-bit MCU) for fast and precise engraving; processes 32 instructions; up to 15,000mm/min engraving speed with LU2-10A laser module

  • More Powerful Laser with True 10W Output Power - Aufero Laser 2 LU2-10A is newly upgraded with a 10W laser module, which makes the cutting speed up to 15,000 mm/min. The compressed point is 0.05mm x 0.1mm. Engraving area is 390*410mm. The optical power reaches to 10W. It can cut 30mm acrylic and 20mm wood. At the same time, the laser module of the engraving machine has a built-in air-assist interface, which is designed for cutting.

  • 【Excellent Mechanical Structure】Aufero Laser enraving machine is designed with low gravitity center of X-axis, providing more stability and ensuring accurate engraving even at high processing speed; 390mm×390mm large engraving range to meet various DIY needs

  • 【Broad Compatibility】Aufero Laser cutting engraving machine is compatible with mature engraving software-LaserGRBL(free), LightBurn(paid); supports Win XP / Win 7 / Win 8 / Win 10, Mac and Linux system; file types BMP, JPG, PNG, JPEG, SVG etc

  • 【4 Safety Protection】→ 1: Active Position Protection; 2:Exposure Duration Detection and Limitation; 3:Laser Beam Safety Guard; 4:Current Safety Control System; full safety protection allows you to hook on your project without any worry

  • 【Dual Eye Protection】Aufero Laser engraver features a protective cover which effecitvely protects your eyes from dazzling beam; comes with a pair of goggles for more protection; works on food, MDF, paperboard, plywood, black acrylic, leather, power coated metal, stone, etc
